Safe, Reliable & Efficient Power Isolation Solutions
We offers high-quality Single Phase Isolation Transformers designed to provide complete electrical isolation between input and output circuits. These transformers enhance safety, reduce electrical noise, and protect sensitive equipment from power disturbances. Available in 500 VA capacity, they support both 220V to 110V step-down and 110V to 220V step-up applications, operating efficiently at 50Hz/60Hz frequency. Ideal for industrial, commercial, laboratory, and electronic equipment applications requiring safe and stable power supply.
| Specification | Details |
|---|---|
| Phase | Single Phase |
| Frequency | 50Hz / 60Hz |
| Primary Voltage | 220V AC (Optional: 110V, 120V, 208V, 230V, 240V) |
| Secondary Voltage | 110V AC (Optional: 120V, 208V, 220V, 230V, 240V) |
| Winding Material | Aluminum / Copper Wire (Optional) |
| Efficiency | ≥ 95% |
| Cooling Mode | Natural Cooling / Air Cooling |
| Insulation Resistance | ≥ 50 MΩ |
| Electrical Strength | 2000V AC / 1 Minute |
| Noise Level | ≤ 35 dB (At 1 Meter) |
| Insulation Grade | Class B (130°C), Class F (155°C), Class H (180°C) |
| Overload Capacity | Up to 1.2 Times Rated Load for 1 Hour |
| Impedance Voltage | Approximately 6% |
| Induced Overvoltage Test | 125Hz / 800V / 1 Minute |
| Total Losses | 10% |
| Operating Temperature | -15°C to +45°C |
| Protection Class | IP20 |
| Weight | 24 Kg |
| Certifications | CE & ISO Certified |
| Warranty | 12 Months |
| Standards Followed | ||||||
| IS5921/1249 | Copper cladbase material in electrical/electronic equipment's | |||||
| IS6297/2026 | Transformers and inductors. | |||||
| IS 6553 | Environmental requirements for semiconductors and Integrated circuits. | |||||
| IS4064 | Airbreak switches | |||||
| IS8828 | MCBs | |||||
| IS 9224 | HRC fuses | |||||
| IS1248 | Indicating instruments | |||||
| IS 6619 | Semiconductor Rectifier equipment safety | |||||
| IS613 | Copper busbars | |||||
| IS2959 | Contactors. | |||||
| IS3231 | Electrical relays | |||||
| IS13703 | Low voltage fuses | |||||
| IS4540 | Mono Crystal line Semi conductor rectifier assembly | |||||
| IS4237 | General requirements for switchgear and control switches | |||||
| IEC62040-2 | Electro magnetic conduction and interference. | |||||
Operational Advantages
- Improves equipment reliability and process stability
- Reduces risk of downtime caused by power issues
- Supports safe operation of sensitive loads
- Designed for dependable performance in industrial environments
Business Advantages
- Extends asset life and lowers maintenance burden
- Improves productivity with consistent power quality
- Offers scalable solutions for diverse industries
- Backed by experienced engineering and service support
Our Expertise
- Aviation
- Machine tool industry
- Food industry
- Automobile industry
- Oil and natural gas industries
- Chemical, petroleum, and pharmaceutical industries
- Textile industries
- Defence and research institutes sectors
* Due to VCS Policy of continuous improvement in product quality, some feature and Size of items may change.
Note:
- Isolation Transformers are designed to convert voltage levels only and do not alter the input frequency.
- These transformers cannot convert a single-phase supply into a three-phase supply.
- Custom voltage ratings, capacities, and specifications are available to meet specific application requirements.
