Reliable Three-Phase Power Isolation for Critical Industrial Applications
We offers high-quality Three Phase Volt Control System's Three Phase Isolation Transformers provide complete electrical isolation between the power source and connected equipment, ensuring enhanced safety, reduced electrical noise, and stable power delivery. Designed for industrial, automation, testing, and critical power applications, these transformers protect sensitive equipment from disturbances while improving system reliability and performance. Available in customized voltage ratings and capacities to suit diverse operational requirements.
| Specification | Details |
|---|---|
| Phase | 3 Phase |
| Capacity | Up to 1000 KVA |
| Primary Voltage | 400V AC (Optional: 120V, 190V, 208V, 220V, 230V, 240V, 380V, 415V, 480V) |
| Secondary Voltage | 208V AC (Optional: 120V, 190V, 220V, 230V, 240V, 380V, 400V, 415V, 480V) |
| Frequency | 50Hz / 60Hz |
| Winding Material | Aluminium / Copper Wire (Optional) |
| Efficiency | ≥ 95% |
| Insulation Resistance | ≥ 50 MΩ |
| Electrical Strength | 3000V AC / 1 Minute |
| Noise Level | ≤ 35 ~ 65 dB (At 1 Meter) |
| Insulation Grade | Class H |
| Wiring Model | As Per User Requirement |
| Cooling Mode | Dry Type Air Cooling |
| Overload Capacity | More than 1.2 Times Rated Load for up to 4 Hours |
| Impedance Voltage | Approximately 6% |
| Operating Temperature | -15°C to +40°C |
| Humidity | ≤ 90% RH (Without Condensation) |
| Altitude | < 1000 m, Non-Corrosive Gas & Conductive Dust Free |
| Enclosure Protection Grade | IP20 (Optional: IP2X, IP3X, IP4X, IP5X, IP6X) |
| Certifications | CE & ISO Certified |
| Warranty | 12 Months |
| Standards Followed | ||||||
| IS5921/1249 | Copper cladbase material in electrical/electronic equipment's | |||||
| IS6297/2026 | Transformers and inductors. | |||||
| IS 6553 | Environmental requirements for semiconductors and Integrated circuits. | |||||
| IS4064 | Airbreak switches | |||||
| IS8828 | MCBs | |||||
| IS 9224 | HRC fuses | |||||
| IS1248 | Indicating instruments | |||||
| IS 6619 | Semiconductor Rectifier equipment safety | |||||
| IS613 | Copper busbars | |||||
| IS2959 | Contactors. | |||||
| IS3231 | Electrical relays | |||||
| IS13703 | Low voltage fuses | |||||
| IS4540 | Mono Crystal line Semi conductor rectifier assembly | |||||
| IS4237 | General requirements for switchgear and control switches | |||||
| IEC62040-2 | Electro magnetic conduction and interference. | |||||
Operational Advantages
- Improves equipment reliability and process stability
- Reduces risk of downtime caused by power issues
- Supports safe operation of sensitive loads
- Designed for dependable performance in industrial environments
Business Advantages
- Extends asset life and lowers maintenance burden
- Improves productivity with consistent power quality
- Offers scalable solutions for diverse industries
- Backed by experienced engineering and service support
Our Expertise
- Aviation
- Machine tool industry
- Food industry
- Automobile industry
- Oil and natural gas industries
- Chemical, petroleum, and pharmaceutical industries
- Textile industries
- Defence and research institutes sectors
* Due to VCS Policy of continuous improvement in product quality, some feature and Size of items may change.
Note:
- Transformer can only convert voltage and CANNOT convert frequency.
- Transformer CANNOT convert single phase voltage to 3 phase voltage.
- Input/output voltage, power rating and whether with shell of all transformers, can be customized according to your requirements.
